HP Compaq NC6110

Screw Listing
Maintenance and Service Guide C–19
Hex Socket HM5.0×9.0 Screw Lock Locations
Table C-11
Hex Socket HM5.0×9.0 Screw Lock
Color Qty. Length Thread
Head
Width
Silver 6 9.0 mm 2.5 mm 5.0 mm
Where used:
1 Two screw locks that secure the system board to the computer only
on HP Compaq nc6110 and nc6120 computer models
(documented in Section 6.24)
2 Two screw locks that secure the system board to the computer
(documented in Section 6.24)
mm
