D–8 Maintenance and Service Guide
Display Component Recycling
11. Remove the screws 1 that secure the backlight cover to the
display panel.
12. Lift the top edge of the backlight cover 2 and swing it
forward.
13. Remove the backlight cover.
Removing the Backlight Cover
To Next Page
