Screw Listing
Maintenance and Service Guide C–13
Phillips PM2.0×7.0 Screw Locations
Table C-7
Phillips PM2.0×7.0 Screw
Color Qty. Length Thread
Head
Width
Silver 2 7.0 mm 2.0 mm 4.5 mm
Where used:
2 screws that secure the fan to the computer (screws are captured on the fan
assembly by an O clip; documented in Section 6.13)
mm

HP Compaq nx6110 Specifications

General

Storage	40 GB to 80 GB HDD
Optical Drive	DVD-ROM or DVD/CD-RW combo
Battery	6-cell Lithium-Ion
Battery Life	Up to 4 hours
Weight	2.7 kg (6.0 lbs)
Processor	Intel Pentium M or Intel Celeron M
RAM	Up to 2 GB DDR SDRAM
Display	15.0-inch XGA TFT
Graphics	Intel GMA 900
Operating System	Windows XP Professional
Networking	10/100 Ethernet
Ports	USB 2.0, VGA, headphone, microphone, RJ-11, RJ-45
Expansion Slots	1 x Type I/II PC Card
