C–14 Maintenance and Service Guide
Screw Listing
Phillips PM2.0×8.0 Shoulder Screw Locations
Table C-8
Phillips PM2.0×8.0 Shoulder Screw
Color Qty. Length Thread
Head
Width
Silver 4 8.0 mm 2.0 mm 5.0 mm
Where used:
4 screws that secure the heat sink to the computer (screws are captured on the
heat sink by C clips; documented in Section 6.14)
mm
