Removal and Replacement Procedures
Maintenance and Service Guide 6–11
4. Remove the Phillips PM1.5×3.0 screw 1 that secures the
Bluetooth board to the notebook.
5. Slide the Bluetooth board forward 2 and out of the clip in
the top cover.
6. Remove the Bluetooth board from the notebook 3.
7. Disconnect the Bluetooth board cable 4 from the board.
Removing the Bluetooth Board
Reverse the above procedure to install a Bluetooth board.
