6–36 Maintenance and Service Guide
Removal and Replacement Procedures
6.17 Display Assembly
1. Prepare the notebook for disassembly (Section 6.3) and then
remove the following components:
a. Switch cover (Section 6.9)
b. Keyboard (Section 6.11)
c. Button board (Section 6.15)
2. Turn the notebook upside down with the rear panel
toward you.
Display Assembly Spare Part Number Information
15.0-inch, SXGA+WVA, TFT
15.0-inch, XGA, TFT
393552-001
393551-001
