7–4 Maintenance and Service Guide
Specifications
Table 7-3
15.0-inch, XGA, TFT Display
Dimensions
Height
Width
Diagonal
30.0 cm
22.9 cm
38.1 cm
11.8 in
9.0 in
15.0 in
Number of colors Up to 16.8 million
Contrast ratio 250:1
Brightness 150 nits typical
Pixel resolution
Pitch
Format
Configuration
0.264 × 0.264 mm
1024 × 768
RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power consumption 5.5 W
Viewing angle +/-35° horizontal, +15/-35° vertical
typical
