HP Compaq nx6115

C–14 Maintenance and Service Guide
Screw Listing
Torx T8M2.5×7.0 Screw Locations
Table C-6
Torx T8M2.5×7.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 13 7.0 mm 2.5 mm 5.0 mm
Where used:
3 screws that secure the system board to the notebook (documented in
Section 6.22)
mm
