5–62 Maintenance and Service Guide
Removal and Replacement Procedures
5.22 Processor
1. Prepare the notebook for disassembly (refer to Section 5.3)
and remove the following components:
a. Optical drive (refer to Section 5.5)
b. Memory module compartment cover (refer to Section 5.6)
c. Mini PCI compartment cover (refer to Section 5.7)
d. Switch cover (refer to Section 5.8)
e. Keyboard (refer to Section 5.10)
f. Display assembly (refer to Section 5.11)
g. Top cover (refer to Section 5.12)
h. System board (refer to Section 5.16)
i. Heat sink module (refer to Section 5.21)
Spare Part Number Information
Intel Pentium 4 560 (3.6-GHz) 377213-001
Intel Pentium 4 550 (3.4-GHz) 374718-001
Intel Pentium 4 540 (3.2-GHz) 374717-001
Intel Pentium 4 530 (3.0-GHz) 374716-001
Intel Pentium 4 520 (2.8-GHz) 374715-001
