Removal and Replacement Procedures
Maintenance and Service Guide 5–41
5.16 System Board
✎
All system board spares kits include a disk cell RTC battery.
✎
When replacing the system board, ensure that the following
components are removed from the defective system board and
installed on the replacement system board:
■ Memory modules (refer to Section 5.6)
■ Mini PCI communications card (refer to Section 5.7)
■ Bluetooth board (refer to Section 5.15)
■ Modem board (refer to Section 5.20)
■ Heat sink module (refer to Section 5.21)
■ Processor (refer to Section 5.22)
Spare Part Number Information
For use on Compaq Presario X6000 models (includes PC
Card cage and expansion port bracket
M24P with 256 MB RAM
M24P with 128 MB RAM
M22P with 64 MB RAM
374711-001
374709-001
374707-001
For use on HP Compaq nx9600 models
M24P with 128 MB RAM
M22P with 64 MB RAM
377209-001
377208-001
