Removal and Replacement Procedures
Maintenance and Service Guide 5–37
5.14 Audio/USB Board
1. Prepare the notebook for disassembly (refer to Section 5.3)
and remove the following components:
a. Optical drive (refer to Section 5.5)
b. Memory module compartment (refer to Section 5.6)
c. Mini PCI compartment cover (refer to Section 5.7)
d. Switch cover (refer to Section 5.8)
e. Keyboard (refer to Section 5.10)
f. Display assembly (refer to Section 5.11)
g. Top cover (refer to Section 5.12)
h. Front panel LED board (refer to Section 5.13)
Spare Part Number Information
Audio/USB board 374761-001
Audio/USB board cable 433822-001
