C–10 Maintenance and Service Guide
Screw Listing
Phillips M2.0×8.0 Screw Locations
Table C-3
Phillips PM2.0×8.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 43 8.0 mm 2.0 mm 4.0 mm
Where used:
1 Two screws that secure the base enclosure small fan to the notebook
(documented in Section 5.19)
2 Three screws that secure the base enclosure large fan to the notebook
(documented in Section 5.19)
mm
