Product Description
Maintenance and Service Guide 1–17
2 Fans (2) Provide airflow to cool internal
components.
Ä
To prevent overheating, do not
obstruct fans. Do not allow a hard
surface, such as a printer, or a
soft surface, such as pillows, thick
rugs or clothing, to block airflow.
3 Memory module
compartment
Contains two memory slots that support
replaceable memory modules. The
number of preinstalled memory
modules varies by notebook model.
4 Label areas (2) Contains the notebook serial number
and other applicable regulatory labels.
5 Battery pack release latch Releases a battery pack from the
battery bay.
6 Battery bay Holds a battery pack.
7 Hard drive bay
Mini PCI compartment
Holds the internal hard drive.
Holds an optional wireless LAN device.
Ä
To prevent an unresponsive
system and the display of a
warning message, install only a
Mini PCI device authorized for
use in your notebook by the
governmental agency that
regulates wireless devices in your
country. If you install a device and
then receive a warning message,
remove the device to restore
notebook functionality. Then
contact Customer Care.
Table 1-8
Bottom Components
(Continued)
Item Component Function
To Next Page
