Removal and Replacement Procedures
Maintenance and Service Guide 5–19
4. Turn the notebook display-side up with the front panel
toward you.
5. Open the notebook as far as possible.
6. Lift up the left and right sides of the switch cover 1 to
detach it from the notebook.
7. Lift the front edge of the switch cover and swing it back
until it rests on the display bezel 2.
Releasing the Switch Cover
