HP Compaq Pro 4300 Maintenance & Serice Guide

Interpreting POST Diagnostic Front Panel LEDs
This section covers the front panel LED codes as well as the audible codes that may occur before or
during POST that do not necessarily have an error code or text message associated with them.
WARNING! When the computer is plugged into an AC power source, voltage is always applied to
the system board. To reduce the risk of personal injury from electrical shock and/or hot surfaces, be
sure to disconnect the power cord from the wall outlet and allow the internal system components to
cool before touching.
NOTE: If you see flashing LEDs on a PS/2 keyboard, look for flashing LEDs on the front panel of
the computer and refer to the following table to determine the front panel LED codes.
Recommended actions in the following table are listed in the order in which they should be
performed.
Not all diagnostic lights and audible codes are available on all models.
Table 10-2 Diagnostic Front Panel LEDs and Audible Codes
Activity Blink
s
Possible Cause Recommended Action
White Power LED flashes
five times, once every
second, followed by a two
second pause. Beeps stop
after fifth iteration but
LEDs continue until
problem is solved.
5 Pre-video memory error. CAUTION: To avoid damage to the DIMMs or the
system board, you must unplug the computer power
cord before attempting to reseat, install, or remove a
DIMM module.
1. Reseat DIMMs.
2. Replace DIMMs one at a time to isolate the faulty
module.
3. Replace third-party memory with HP memory.
4. Replace the system board.
White Power LED flashes
six times, once every
second, followed by a two
second pause. Beeps stop
after fifth iteration but
LEDs continue until
problem is solved.
6 Pre-video graphics error. For systems with a graphics card:
1. Reseat the graphics card.
2. Replace the graphics card.
3. Replace the system board.
For systems with integrated graphics, replace the
system board.
White Power LED flashes
seven times, once every
second, followed by a two
second pause. Beeps stop
after fifth iteration but
LEDs continue until
problem is solved.
7 System board failure (ROM
detected failure prior to
video).
Replace the system board.
White Power LED flashes
eight times, once every
second, followed by a two
second pause. Beeps stop
after fifth iteration but
LEDs continue until
problem is solved.
8 Invalid ROM based on bad
checksum.
1. Reflash the system ROM with the latest BIOS
image.
2. Replace the system board.
Interpreting POST Diagnostic Front Panel LEDs 145

HP Compaq Pro 4300 Specifications

General

Full HD	No
Panel type	TN
LED backlight	Yes
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Tcase	65.3 °C
Bus type	DMI
Processor cache	3 MB
Processor cores	2
Processor model	i3-3240
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-3200 Desktop Series
Processor socket	LGA 1155 (Socket H2)
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	55 W
CPU multiplier (bus/core ratio)	34
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Product type	All-in-One PC
Motherboard chipset	Intel® H61
Internal memory	4 GB
Memory slots type	SO-DIMM
Memory clock speed	1600 MHz
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Compatible memory cards	SD
Autonomy mode	-
Storage drive interface	Serial ATA
On-board graphics card ID	0x152
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 2500
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
RMS rated power	4 W
Wi-Fi standards	Not supported
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Headphone outputs	1
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Bundled software	Adobe Flash Player\\r HP Marketplace\\r Bing\\r Microsoft Internet Explorer\\r PDF Complete Corporate Edition\\r WinZip Basic\\r Yahoo\\r Compre Office
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Processor ARK ID	65690
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Thermal solution specification	PCG 2011C
Intel Secure Key Technology version	0.00
Intel Identity Protection Technology version	1.00
Product color	Black
Country of origin	China
Total megapixels	1.3 MP
AC adapter power	150 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	220 mm
Width (with stand)	507 mm
Height (with stand)	406 mm
Weight (with stand)	5730 g
