Memory Access Panel
The memory access panel is located on the rear, right side of the computer (viewed from behind).
You must remove it to access the memory modules and RTC battery.
Figure 6-3 Memory access panel location
To remove the memory access panel:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 33).
2. Remove the center access panel (see
Hinge Cover Panel on page 34).
36 Chapter 6 Removal and Replacement Procedures All-in One (AIO) Chassis
