Stand
The stand is secured with three Torx screws. You must remove the center access panel to remove
the stand.
To remove the stand:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 33).
2. Remove the center access panel (see
Hinge Cover Panel on page 34).
3. Remove the three silver Torx screws (1) that secure the stand to the computer.
4. Lift the memory and drive access panel latches (2).
5. Slide the stand toward the top of the computer slightly (3), and then lift the stand off the
computer (4).
Figure 6-41 Removing the stand
To replace the stand, reverse the removal procedures.
Stand 61
