How to define Palette A
The following steps explain how to define Palette A.
Repeat this procedure to define each of the other pens.
NOTE: The palette you have just defined will take effect only when you select it to be the current
palette, as explained in To select a palette.
Instructions
Select (using the keys)
Then press:
1.
Select Palette A
Set-up menu Enter
2. HP-GL/2 Enter
3. Define palette Enter
4. Palette A Enter
5. Select pen to change (in this example 3). Pen 3 Enter
6. The current width assigned to this pen is
displayed, for example Width=0.13mm.
Width = 0.13mm Enter
7.
Scroll to the width you want. 0.35mm Enter > Back
8.
Scroll to Color. The current color
assigned to the pen is displayed (in this
example 4)
Color = 4 Enter
9.
Scroll to the color you want.
Color = 110 Enter > Back
10.
If both width and color are correct (for
Pen 3), press Back four times
Pen 3 To p
