Window Lock Sensor Left 345
Removal & Installation
Window Lock Sensor Left
Removal
1. Remove the Left Curing Cover
⇒
See page 328.
2. Disconnect the Left Window Lock Sensor.
3. Remove the cable of the Left Window Lock Sensor from
a holding point on the Left Curing Cover.
4. Remove two T-8 screws that secure the Left Curing
Sensor.
WARNING!: Switch off the printer and remove the power cable.
To Next Page
