34 Printer systems
Printer systems
Related tests, utilities, and calibrations
• Front Panel Service Test ⇒ Page 121
Service parts
• Front Panel ⇒ Page 270.
Removal and installation
• Front Panel ⇒ Page 353.
Front Panel Electronics Diagram
NOTE: The front panel is connected to the Formatter Board through a USB BUS and 5V
standby & reset line. The standby and reset line is what enables you to start the Main
Power Supply from the ON/OFF button of the front panel.
