HP Designjet L25500 Printer series - Page 443

OMAS Controller Card 437
Removal & Installation
OMAS Controller Card
Removal
1. Remove the Right Connector Cover ⇒ See page 341.
2. Remove three T-20 screws (Type A) that secure the
Main PCA cover.
3. Remove the Main PCA Cover from the Printer.
4. Disconnect the OMAS Controller Card to OMAS
ribbon cable.
WARNING!: Switch off the printer and remove the power cable.
1
2
