438 Chapter 8 Removal & Installation
Removal & Installation
5. Disconnect the OMAS Controller Card to PrintMech
and Sausalito PCI connection cables.
6. Remove one T-10 screw (Type I) that secures the
OMAS Controller Card.
7. Disconnect the OMAS Controller Card from the Main
PCA and remove from the Printer.
CAUTION: To remove the OMAS Controller
Card without damaging it on the Emodule
cover, you will need disconnect it first and then
rotate it slightly in the direction indicated.
NOTE: After installing a new OMAS
Controller Card, perform the following:
• “5.3.3 OMAS Temperature Calibration”
⇒
page 211.
To Next Page
