HP Designjet Z3100 series Reference Guide

2 Personalizing the printer
Turn printer on and off
Tip The printer is Energy Star compliant and can be left powered
on without wasting energy. Leaving it on improves response time
and overall system reliability. When the printer has not been used
for a certain period of time (30 minutes by default), it saves power
by going into sleep mode. However, any interaction with the printer's
front-panel display returns it to active mode, and it can resume
printing immediately. To change the sleep mode time, see Using
your printer on DVD.
NOTE In sleep mode, the printer wakes up from time to time to do
maintenance service to the printheads. This avoids the need of
doing long preparation after long idle periods.
The printer has three levels of power consumption.
●
Plugged in: the power cord is plugged into the back of the printer
●
Switched on: the switch at the back of the printer is in the on position
●
Powered on: the Power key on the front panel shows a green light
If you wish to turn the printer on or off or reset the printer, the normal and
recommended method is to use the Power key on the front panel.
However, if you plan to store the printer indefinitely or the Power key does
not seem to work, you are recommended to power it off using the Power
key, and then also switch off the power switch at the rear.
ENWW
Turn printer on and off
5
Personalizing the printer

HP Designjet Z3100 series Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	2400 x 1200 optimized dpi
Number of Inks	12
Ink Types	Pigment-based
Hard Disk	40 GB
Operating Systems Supported	Windows, macOS
Connectivity	USB 2.0, Ethernet
Media Handling	Roll feed
Print Languages	HP-GL/2, HP-RTL, CALS G4
Line Accuracy	+/- 0.1%
Dimensions (W x D x H)	1770 x 1047 mm
Media Sizes Supported	Up to 44 inches wide (roll), up to 42 x 60 inches (sheet)
Print Margin (roll)	5 mm (top), 5 mm (right), 5 mm (left), 5 mm (bottom)
