2. Standing behind the printer, rest the spindle's black end on the left side
roll holder. Do not put the end completely into the roll holder.
3. Rest the blue end of the spindle on the right side roll holder. If you are
loading the gray spindle, ensure the rounded side of the spindle top is
resting on the roll holder.
4. With both hands, push the spindle into both roll holders at the same
time. The spindle snaps in place.
ENWW
Load a roll into the printer
13
Paper handling

Other manuals for HP Designjet Z3100 series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Designjet Z3100 series and is the answer not in the manual?

HP Designjet Z3100 series Specifications

General IconGeneral
Print TechnologyThermal Inkjet
Maximum Print Resolution2400 x 1200 optimized dpi
Number of Inks12
Ink TypesPigment-based
Hard Disk40 GB
Operating Systems SupportedWindows, macOS
ConnectivityUSB 2.0, Ethernet
Media HandlingRoll feed
Print LanguagesHP-GL/2, HP-RTL, CALS G4
Line Accuracy+/- 0.1%
Dimensions (W x D x H)1770 x 1047 mm
Media Sizes SupportedUp to 44 inches wide (roll), up to 42 x 60 inches (sheet)
Print Margin (roll)5 mm (top), 5 mm (right), 5 mm (left), 5 mm (bottom)
