Carriage Interconnect Wiper 91
Ink Supplies
The binary number needs to be read from right to left so that the 1st bit corresponds to the right one of
the binary number. For example, the error code 4099 is converted to binary number 10000000000011.
So using the table above, the error code means “FAILS_LOGICAL_V”, “FAILS_CONTINUITY” and
“MISMATCH”.
Carriage Interconnect Wiper
Whenever you replace the Printhead, check the empty slots to see if they need cleaning. In extreme
circumstances, when a Printhead is inserted, it is possible that the Printer will not recognize it due to the
build-up of ink on the electrical connection between the Printhead and the Carriage Assembly.
Included with the HP Designjet Printer, is a Carriage Interconnect Wiper. This tool is provided in a
separate package. It also contains replacement sponges and an instruction sheet. This tool should be used
for cleaning the electrical interconnects of both the Carriage Assembly and the Printhead.
If the front panel displays the message “Reseat” or “Replace” next to the offending printhead, try cleaning
the flex circuits of the Carriage and the Printheads.
Warranty Information for Ink Supplies
Ink Cartridge
The warranty for the Ink Cartridges will end when one of the following occurs:
• 30 months from the date of manufacture
or
• When the advertised deliverable ink has been reached
6th TEMP_EXTREMELY_LOW 16th FAILS_ENERGY_CALIBRATION
7th TEMP_TOO_HIGH 17th EMPTY_DUMMY
8th TEMP_TOO_LOW 18th FULL_DUMMY
9th BAD_ACUMEN_INFO 19th END_OF_LIFE
10th NO_PEN 20th OUT_OF_WARRANTY
NOTE: The Carriage Interconnect Wiper is part of the Maintenance Kit. All the instructions
needed to use the Carriage Interconnect Wiper will be packaged with the kit.
CAUTION: Do not touch, wipe or attempt to clean the printhead nozzles. This can damage
the printhead and reduce print quality.
Bit Meaning Bit Meaning
