Entering the Service Calibrations Menu 175
Service Calibrations
While the Carriage is moving the Front Panel shows the actual position and the direction of move-
ment and prompts you to press ENTER when done.
8. The Front Panel shows the actual left offset value and the system calculates the Fight Scan-Axis Offset.
9. Once the Right Scan-Axis Offset has been calculated the Front Panel prompts you use the Up/
Down keys to move the carriage until the LEFT
edge of the Right Alignment Mark is correctly
aligned with the Primer Positioning Indicator and press ENTER.
