Troublshooting a failure with the Take UP Reel (TUR) 9
Troubleshooting
Troublshooting a failure with the Take UP Reel (TUR)
Use this section to troubleshoot failures with the TakeUP Reel.
Take Up Reel LED status information
LED
status
Issue Print job
interupted
Possible cause Print job
interrupted?
Blinking
quickly
Take Up Reel
not winding
Yes Sensor beam blocked for
more than 3 seconds
Ensure the Take Up Reel sensors
are not blocked by a strip of
paper, the collection bin or other
objects.
Also ensure the Take Up Reel
power switch is in the On posi-
tion.
Blinking
slowly
Take Up Reel
not winding
No The sensor cables are
loose or unplugged
Ensure the sensor cables are cor-
rectly connected.
Solid red Take Up Reel
not winding
No There is too much resis-
tance on the Take Up Reel
motor
ENSURE THAT THE TUR Spindle
Lever is CLOSED! Ensure the
paper is not winding too tightly.
A loop-shaping core should be
inserted and hanging down.
Solid green Take Up Reel
not winding
No The Take Up Reel power
switch is in the Off posi-
tion
Ensure the Take Up Reel power
switch is in the On position.
Solid green Take Up Reel
winding in the
wrong direc-
tion, and not
stoppinjg the
job.
No The Take Up Reel wind
direction switch is in the
wrong winding position.
after 3 seconds, the
printer will recognize the
problem and interupt the
print job. In this case, see
the first error listed in this
table.
Flip the Take Up Reel wind-direc-
tion switch to the correct posi-
tion.
NOTE: If the LED is flashing but there is no message on the front panel, restart the printer.
