272 Chapter 8 Removal & Installation
Removal & Installation
Left Trim
Removal
1. Remove the Output Platen
⇒
See page 398.
2. Remove six T-15 screws that secure the Left Trim.
3. Carefully remove the Left Trim from the Printer.
WARNING!: Switch off the printer and remove the power cable.
