HP Designjet Z6100 Printer series - Formatter Battery

376 Chapter 8 Removal & Installation
Removal & Installation
6. Release the plastic locating pin that secures the Main
PCA Formatter.
7. Remove the Main PCA Formatter from the Printer.
NOTE: When installing the Main PCA Formatter, make sure that you first locate it on the plastic locating
pin and then install the screws.
