68 Chapter 2 System Error Codes
System Error Codes
• Replace the Encoder Disc and Sensor ⇒ Page 417.
System Error:
58:10
Problem Description:
An error detected with the Color Sensor.
Corrective Action:
Try the following:
• Switch the Power OFF from the back of the Printer and disconnect the Power cord. Reconnect the
power cord and power On the Printer.
• Check that the Printer has the latest firmware version. If not, update the Firmware to the latest version.
• Perform the Color Sensor test.
• If the error is displayed during the printer’s initilization, perform the Color Sensor Test from the
diagnostic boot mode ⇒
page 119.
• If the error is displayed after the printer has initialized, for example when performing a Color
Calibration/Linearization, perform the Spectrophotometer test ⇒
page 148.
• If the Color Sensor Shutter opens and closes, then replace Color Sensor Assembly ⇒
Page 392
.
• If the Color Sensor Shutter is not activated:
• If the Color Sensor Actuator Lever does not elevate or is broken:
1. Replace the Color Sensor Actuator Assembly ⇒Page 395.
2. Clean the Encoder Strip using a lint free cloth with damp water ⇒ Page 454.
• If the SOL Actuator Lever elevates but does not always catch the shutter, clean the Encoder Strip
using a lint free cloth with damp water ⇒ Page 454.
• If the System Error continues,
replace the Carriage PCA
⇒
Page 334
.
System Error:
61:01
Problem Description:
The file format is incorrect and the Printer cannot process the job.
Corrective Action:
Try the following:
• Switch the Power OFF from the back of the Printer and disconnect the Power cord. Reconnect the
power cord and power On the Printer.
• Check the graphic language setting of the Printer (Refer to the User’s Guide).
• Resend the file to the Printer.
• Check that the Printer has the latest Firmware version. If not, update the Firmware to the latest
version.
• If printing from a RIP check that the RIP version is the latest available.
System Error:
61:04.1
