HP System
HP Vivera pigment ink
Work with millions of color combinations across
a wide color gamut and wide range of media.
The Original HP Vivera pigment inks include the
HP Three-black ink set that produces a broad range
of blacks, subtle transitions, true gray neutrality,
and rich black density. Exclusive Original HP Vivera
pigment ink formulations are delivered by HP 91
Printheads that are designed to achieve precise,
accurate placement of smaller drops at high speed.
Each printhead prints two colors of ink with 1,056
nozzles per color. Working together, these components
produce a range of vibrant colors, smooth neutral
gray transitions, crisp text, and fine line accuracy
for a wide color gamut, incredible detail, and
photo-image quality.
HP Media
Choose from more than 50 Original HP large-format
media substrates for a broad range of applications,
including bond, coated, photo and proofing papers;
technical and graphic papers and films; and backlit,
self-adhesive, banner and sign, fabric/textile and
fine arts printing materials. Original HP media is
designed together with HP Vivera pigment inks to
produce consistently outstanding image quality that
you can count on—from photo-quality images to
high-quality posters and banners to crisp line drawings.
HP Services
Want to ensure your printer is always available and
productive? Check out HP Care Pack Services for
installation and multi-year on-site services. Experts
are available with technical phone, web and on-site
services to make sure you get the most efficient use of
your printer. Competitively priced, flexible packages
let you select service levels, hours of coverage and
response times that meet your needs.
HP technology leadership
Outstanding speed
HP Double Swath Technology provides breakthrough
speed and performance. The HP Designjet Z6100
Printer series includes two sets of four HP 91 Vivera
pigment ink printheads, creating a wide print swath—
up to 1.8 inches—and a high firing frequency to deliver
prints with amazing speed.
The first-ever HP Optical Media Advance Sensor
allows you to print at top speeds and still get great
output results. This breakthrough technology improves
paper-advance control and accuracy, so the printer
can print at higher speeds across multiple environmental
conditions without impairing image quality.
Amazing color
The HP Embedded Spectrophotometer, with i1 Color
Technology from GretagMacbeth, is mounted on
the printer carriage for accurate printer calibration
measurements that deliver print-to-print and printer-to-
printer color consistency. It revolutionizes professional
color workflows by systematically creating media profiles,
allowing users to automatically generate custom CMYK
ICC profiles for their preferred media. Also, with the
optional HP Advanced Profiling Solution, you can edit
and modify existing profiles and create RGB profiles.
4
HP DreamColor Technologies make it easy for you
to produce accurate, predictable and consistent
color across different printers, presses and media.
The HP Designjet Z6100 Printer series comes
equipped with HP DreamColor Technologies: HP
Professional PANTONE
®
emulation, HP’s closed-loop
color calibration and automatic ICC profiling with
the HP embedded spectrophotometer and software.
The result? The HP Designjet Z6100 Printer series,
plus HP media and HP 91 Vivera pigment inks,
produce vivid and accurate color prints—print to
print and printer to printer.
High productivity
The HP Easy Printer Care Tool lets you easily
navigate through color-management, printing and
job-management workflows, and the HP Color Center
provides easy-to-use, step-by-step instructions on how
to add new media and calibrate the printer. Plus, the
HP Designjet Z6100ps printer’s accounting tool allows
you to easily track supplies use by job, while the job
submitter tool lets you submit your HP-RTL, HP-GL/2,
CALS G4, PostScript, PDF, TIFF, EPS and JPEG files
directly to the printer.
3
HP Optical Media Advance Sensor HP Embedded SpectrophotometerHP Vivera Pigment Inks HP Media HP Printhead
4
Non-Adobe PostScript
®
printers require the HP Advanced Profiling Solution or a 3rd party RIP that supports media profiling.

HP DesignJet Z6100 Specifications

Printing Specifications

fast print speed (coated paper)	720 ft2/hr
best print speed (glossy paper)	98 ft2/hr
maximum print speed (plain paper)	1134 ft2/hr
print resolution maximum	2400 x 1200 optimized dpi
minimum line width	0.003 in.
maximum print length	575 ft

Memory and Storage

standard memory	256 MB
hard disk capacity	40 GB

Media Specifications

media weight	Up to 430 g/m2
media thickness	Up to 22 mil
maximum roll length	575 ft
media size (42-inch models)	24- to 42-inch rolls
media size (60-inch models)	24- to 60-inch rolls

Power

maximum power consumption	350 watts
powersave mode power consumption	23 watts
off mode power consumption	0.4 watts
input voltage	100 to 127 VAC (+/- 10%), 4 amp; 220 to 240 VAC (+/- 10%), 2 amp

Operating Environment

operating temperature range	41 to 104° F
recommended operating temperature	59 to 95° F
storage temperature range	-13 to 131° F
operating humidity range	20 to 80% RH

Weight and Dimensions

printer dimensions (42-inch model)	77.5 x 27.5 x 53 in.
printer dimensions (60-inch model)	97 x 27.5 x 53 in.
shipping dimensions (42-inch model)	89 x 29.5 x 47.9 in.
shipping dimensions (60-inch model)	107.3 x 29.5 x 53.6 in.
printer weight with stand (42-inch model)	262 lb
printer weight with stand (60-inch model)	333 lb
shipping weight (42-inch model)	429.9 lb
shipping weight (60-inch model)	564.4 lb
