9. The front panel shows the actual right offset value and then the right alignment position.
10. The calibration process continues, and the front panel shows the new nominal offset value. Press
OK to continue.
11. When the calibration is complete, the result is displayed on the front panel. Press OK to leave the
calibration process.
12. Replace the Right Cover See Right Cover on page 216.
Reset vacuum calibration
The purpose of this Service Calibration is to reset the nominal values of the Vacuum Calibration.
NOTE: Reset the vacuum calibration only if the vacuum fans are working (the printer can turn them on
without system errors), but the vacuum pressure is incorrect and there are carriage crashes. The existing
calibration will be lost.
1. In the Service Calibrations submenu, select Vacuum Calibration and press OK.
ENWW
Entering the Service Calibrations menu
139
Service calibrations
