R T-15 - Pan Taptite 0515-1916
S T-15 18.4 Pan Machined Q6651-20179
Window (42-inch)
Removal
WARNING! Switch off the printer and remove the power cable.
1. Open the Window.
2. Unclip the Window hinges from the Top Cover.
NOTE: Since the hinges are very hard to unclip, it is recommended that you use a screwdriver
or other tool to forcefully unclip the Window hinges from the Top Cover.
ENWW
Disassembly order
213
Removal and
installation
