3. Remove the Window from the printer.
Installation of New Window
1. Identify the two ends of the Window hinge (four in total) - one end is clipped to the Window and
the other to the Top Cover.
2. Slide the Window hinges on to the Window.
3. Clip the Window Hinges to the Top Cover.
NOTE: Since the hinges are very hard to clip, you will need to forcefully clip the Window
hinges to the Top Cover.
214 Chapter 8 Removal and installation ENWW
