4. Remove two T-15 screws (Type J) that secure the Right Cover.
5. Remove one T-15 screw (Type J) and one T-20 screw (Type A) that secure the Right Cover from
the rear of the printer.
6. Remove the Right Cover from the printer.
CAUTION: When installing the Right Cover, make sure you leave the Maintenance Cartridge
Door open, otherwise you could damage the Maintenance Cartridge Door Sensor.
Right Trim
Removal
218 Chapter 8 Removal and installation ENWW
