3. Remove the Front Panel See Front Panel on page 245.
4. Disconnect the Primer Assembly cable from the Interconnect PCA.
5. Unroute the cable from the cable clamp.
6. Move the cable out of the Electronics Module.
248 Chapter 8 Removal and installation ENWW
Removal and
installation
