WARNING! Switch off the printer and remove the power cable.
1. Remove the Right Cover See Right Cover on page 216.
2. Disconnect the Primer Valve Cables.
3. Disconnect the Primer Valve tubes.
4. Remove two T-15 screws.
250 Chapter 8 Removal and installation ENWW
