5. Remove the Primer Valves.
Primer Valve Cables
Removal
WARNING! Switch off the printer and remove the power cable.
1. Remove the Right Cover See Right Cover on page 216.
2. Remove the Right Connector Cover
See Right Connector Cover on page 238.
3. Disconnect both Primer Valves from the Interconnect PCA.
4. Unplug the power cable.
ENWW
Disassembly order
251
Removal and
installation
