4. Remove the Top Cover See Top Cover (60-inch) on page 229.
5. Remove the Rear Door
See Rear Door (60-inch) on page 237.
6. Remove the Right Connector Cover
See Right Connector Cover on page 238.
7. Disconnect the Trailing Cable from the Interconnect PCA and the Main PCA.
8. Unclip the Trailing Cable ferrites from the left side of the Electronic Module.
9. Disconnect the Trailing Cable.
266 Chapter 8 Removal and installation ENWW
Removal and
installation
