HP Designjet Z6200

8. Remove two T-15 attachment screws (Type J) from the Scan-Axis Beam.
NOTE: Be very careful not to damage the encoder strip while removing the attachment screws.
9. Remove two T-15 attachment screws from the Scan-Axis Beam.
10. Remove one T-15 attachment screw.
ENWW
Disassembly order
291
Removal and
installation
