11. Unclip the Spittoon attachment point so that you can rotate it in the next step.
12. Rotate the Left Spittoon clockwise.
13. Remove the Left Spittoon from the printer.
NOTE: After installing the new Left Spittoon, make sure you perform the following Service Utility:
●
Reset life counter left spittoon
Reset Life Counters on page 108.
Encoder Strip and Encoder Sensor
Removal
292 Chapter 8 Removal and installation ENWW
Removal and
installation
