8. Fully tighten the T-20 horizontal attachment screw which secures the OMAS to the printer.
9. Clip the Media Sensor to the Center Guide.
10. Clip the OMAS access cover back into place by sliding one edge of the cover into the slot and
then applying enough pressure to it so you can clip it into the other slot.
11. Calibrate the OMAS
See OMAS Calibration on page 142.
12. If the calibration fails, repeat the procedure from step 4 1 above to ensure it is correctly
positioned.
Interconnect PCA
Removal
ENWW
Disassembly order
323
Removal and
installation
