7. Remove the Formatter from the printer.
NOTE: When installing the Formatter, make sure that you first locate it on the plastic locating pin and
then install the screws.
Hard Disk Drive (HDD)
Removal
WARNING! Switch off the printer and remove the power cable.
NOTE: You must never replace both the Hard Disk Drive and the Ink Supply Tubes and Trailing Cable
at the same time. If both parts need to replaced, you must first replace one part and then power on the
printer until it initializes completely. Then you can power off the printer and replace the other part.
1. Remove the Jetdirect Card (if installed).
340 Chapter 8 Removal and installation ENWW
Removal and
installation
