HP Designjet Z6200

6. Disconnect all the cables connected to the right Interconnect PCA and the Main PCA.
7. Unroute all the disconnected cables so they are clear of the Electronics Module.
8. Remove two T-20 screws (Type B) that secure the right-hand-side Electronics Module.
352 Chapter 8 Removal and installation ENWW
Removal and
installation
