HP Designjet Z6200

8. Press the two sides of the Carriage PCA Cover, unclip it from the Carriage Assembly and remove
it.
9. Release the clip and disconnect the ESP cable from the Carriage PCA.
10. Move the carriage sufficiently to the right to gain access the ESP attachment screws.
