3. Remove the Take-Up Reel Deflector from the printer.
4. Remove the two T-20 screws that attach the Left-Hand Deflector Support to the Left Leg Assembly.
5. Remove the Left-Hand Deflector Support.
ENWW
Disassembly order
413
Removal and
installation
