HP DL360 G7 Server specifications
Base unit Baseline Options
DL360 G7 1U chassis, dual socket No additional options supported.
Processor Intel E5620 Quad Core /2.4 GHz
(Westmere)
3 memory channels per CPU with up
to 3 RDIMMs per channel (most
applications use 1 or 2 RDIMMs per
channel to optimize memory speed)
• Intel X5670 six Core/2.93 GHz
(Westmere)
• Upgradable to dual processors for
either E5620 or X5670
Memory 2 GB DDR3 RDIMMs (1333 MHz) 4 GB DDR3 RDIMMs (1333 MHz)
HW RAID 1 P410i RAID controller with 256MB
cache and battery backup. Optioned
as RAID 1 or 5
N/A
Hot-Plug disk
drive cage
4 Small Form Factor 2.5” hot-plug
hard drives bays are available when
an optical drive is installed.
HP offers servers with 8 drive bays
that do not support an optical drive
(not supported by Avaya).
Disk drive 146GB SAS 2.5" 10K RPM 6G DP
Hard Drive. Two base
configurations:
• 136 total: RAID 1, 2 x 146GB
drives
• 272 total: RAID 5, 3 x 146GB
drives
Options:
• Additional 146GB 10K RPM drive
(4 max. with optical drive)
• High performance 146GB 15K
drives
• 300GB 10K HDD
NICs 4 integrated ENET Gigabit NIC ports
with TCP offload engine (included
on motherboard)
HP NC382T PCI Express Dual Port
Gigabit NIC expansion card
(Broadcom 5709 silicon)
PCI slots Two PCI-Express Gen 2 expansion
slots: (1) full-length, full-height slot
and (1) low-profile slot (1-FL/FH x 16
PCIe & 1-LP x 8 PCIe Riser
Meeting Exchange Recording uses
a PCI-X riser in place of the low
profile PCIe riser in the standard
server.
Removable
media
Slim line SATA DVD-RW optical
drive (used in all Avaya
configurations)
No additional options supported.
Power supply 460 W hotplug AC power supply
• 750W AC power supply
• 1200W DC power supply
• Single and dual power supply
configurations
HP DL360 G7 Server specifications
Installing the HP DL360 G7 Server November 2010 11
