HP DL380P User Manual

Operations 30
7.
Secure the full-length expansion board retainer.
8. Install the access panel (on page 23).
9. Install the server into the rack ("Installing the server into the rack" on page 36).
10. Connect each power cord to the server.
11. Connect each power cord to the power source.
12. Power up the server (on page 21).
Remove the air baffle
CAUTION: For proper cooling do not operate the server without the access panel, baffles,
expansion slot covers, or blanks installed. If the server supports hot-plug components, minimize
the amount of time the access panel is open.
To remove the component:
1. Power down the server (on page 21).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Extend or remove the server from the rack ("Extend the server from the rack" on page 21).
4. Remove the access panel (on page 22).
CAUTION: Do not detach the cable that connects the battery pack to the cache module.
Detaching the cable causes any unsaved data in the cache module to be lost.
IMPORTANT: It is necessary to remove the PCI riser cage only if there is a full-length expansion
board installed.
Storage Networks
www.storagenetworks.com
Authorized HP Reseller
Spare Parts:
http://www.storagenetworks.com/products/servers/hp/DL380G8/dl380pg8_servers_landing.php

HP DL380P Specifications

General

Product Line	ProLiant
Rack Height	2U
Processor Sockets	2
Memory	Up to 768 GB
RAID Levels	0, 1, 5, 6, 10, 50, 60
Management	HP iLO (Integrated Lights-Out)
Server Type	Rack
Processor	Intel Xeon E5-2600 series
Chipset	Intel C600
Memory Slots	24
Memory Type	DDR3
Drive Bays	25 SFF
Hard Drive Interface	SAS, SATA
Network	Gigabit Ethernet
Power Supply	Redundant Power Supplies supported
Expansion Slots	6 PCIe Gen3 slots
Operating System Support	Windows Server, Linux, VMware
Remote Management	HP iLO (Integrated Lights-Out)
Form Factor	Rackmount
