HP DL385-G7

Cabling 57
Cabling
SAS hard drive cabling
Connect the SAS power cable from the primary drive cage (drive cage containing drives 1 - 8) to the
primary SAS power connector on the system board.
If a secondary drive cage (drive cage containing drives 9 - 16) is installed, connect a SAS power cable
from the secondary drive cage to the secondary SAS power connector on the system board.
