HP Elite x2 1011 G1 Maintenance And Service Guide

2 External component identification
Slate edge components
Item Component Description
(1) Internal microphone Record sound.
(2) Vents Enable airflow to cool internal components.
NOTE: The slate fan starts up automatically to cool internal
components and prevent overheating. It is normal for
the internal fan to cycle on and off during routine operation.
(3) Rear-facing webcam Records video and captures photographs. Some models
allow you to video conference and chat online using
streaming video.
For information on using the webcam:
●
Windows 10 – Type camera in the taskbar search box,
and then select Camera.
●
Windows 8 – Access HP Support Assistant. To access HP
Support Assistant on the Start screen, select the HP
Support Assistant app.
●
Windows 7 – Select Start > All Programs >
Communication and Chat > HP WebCam.
(4) Camera flash Provides light for rear-facing webcam photos.
(5) Rotate lock button When the slate is on, press the rotate lock button to lock
the autorotate feature of the display. To unlock
the autorotate feature, press the button again.
(6) Volume button Controls speaker volume on the slate.
6 Chapter 2 External component identification

HP Elite x2 1011 G1 Specifications

General

Stepping	F0
Tjunction	95 °C
Processor code	SR23L
Processor cache	4 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™ M
Processor series	Intel Core M-5Y Mobile series
Processor threads	4
Processor codename	Broadwell
Processor frequency	1.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor package size	30 x 16.5 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.6 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	14 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	4.5 W
Scenario Design Power (SDP)	3.5 W
Configurable TDP-down frequency	0.6 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	256 GB
Display diagonal	11.6 \
Touch technology	Multi-touch
Graphics card	HD Graphics 5300
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Processor ARK ID	84669
Processor socket	BGA 1234
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Near Field Communication (NFC)	-
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of origin	China
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Battery capacity	- mAh
Battery life (max)	9 h
Platform	Windows
Operating system installed	Windows 8.1 Pro

Weight and Dimensions

Depth	192.7 mm
Width	298 mm
Height	10.7 mm
Weight	780 g
